COMPONENT EXPLODED VIEW
Grille MP415
128-00426-01
Screw (4)
729-90002-16
No. 12 x 1
Pole Mount MPRO
339268-001
Gasket, STND Cup
359-00212-00
Screw (4)
884-41210-16
10 x 1
PAN, PH, BLK
Screw (12)
884-41110-12
No. 10 x 3/4
PN HD
Screw (8)
804-41110-12
No. 10-32 x 3/4
PAN PH, BLK,
ZINC
Gasket, HDL (2)
382-00337-00
T-Nut (8)
61861
10-32
Screw (6)
882-51110-12
6 x 3/4
OV PH
Network
336821-002
Enclosure
MP415
(Not for
Sale)
Handle, MP Series (2)
923-00022-01
Speaker, High Freq
2406H
(337213-001X)
Diaph Repl
D8R2406
2406H-1
(337213-003X)
Diaph Repl
D8R2406-1
Screw (6)
824-41110-12
No. 10 PAN PH
Threaded Adapter
885-00059-00
Baffle MP415
(Not for Sale)
Grille Bumper (5)
Stick On
350922-001
Screw (4)
804-01110-16
10-32 x 1
FIL,PH, BLK,
ZINC
Screw (10)
744-41110-08
No. 10 PAN PH
Speaker, Low Freq
2033H
(124-37007-00X)
Cone Repl
C8R2033
Foot, (4)
353445-001
Nameplate
336825-001
