JBL PRX425 User Manual

JBL PRX425
JBL PRX425
COMPONENT EXPLODED VIEW
Handle Cup (2)
444686-001
Gasket, Handle (2)
444827-001
Screw (8)
864-41400-08
#8 10 x 1/2
HILO,PAN,PH,CL,
ZINC
Handle Bar (2)
364855-003
Screw (8)
815-73414-15
M5X0.8X15MM
SOCKHD,HEXSOCK,
BLK
Feet (4)
444707-001
Screw (8)
883-41110-08
8 x 1/2
PAN,PH,PB,BLK
ZINC,LCS
Driver, Low Freq.(2)
M115-8A
(124-67001-01X)
Screw (16)
804-41110-12
10-32 X 3/4
PAN,PH,PB,BLK,
ZINC,LCS
Gasket (2)
360-70002-01
Rear
Dome (2)
71646-03
Grille
Assembly
444801-002
Screw (4)
444811-002
Low Profile
Screw (10)
882-41110-10
6 x 5/8
PAN,PH,PB,BLK
ZINC,LCS
Logo Nut (2)
444829-001
Grille Badge
Assembly
5006459
Horn
338800-001
Gasket, Horn
351577-001
Screw (10)
804-41110-16
10 - 32 x 1
PAN,PH,BLK
Driver, High Freq.
2414H-C
(5000169X)
Enclosure for PRX425
(Not Available for Sale)
Input Cup Assembly
5011408
Screw (4)
882-41110-10
6 x 5/8
PAN,PH,PB,BLK
ZINC,LCS
Screw (4)
882-41110-10
6 x 5/8
PAN,PH,PB,BLK,
ZINC,LCS
Input Cup
5011410
Input Cip Gasket
5013128
Label
5012394
Grille Support (2)
444778-001
T-Nut (4)
61861
10-32
Bracket (6)
444777-002
Side 15”
(internal)
Bolt, (12)
352051-001
M10 x 25MM
HEX,BLK
Screw (12)
883-41100-08
8 x 1/2
PAN,PB,CLR,ZINC,
LCS
T-Nut (26)
61861
10-32
(baffle)

JBL PRX425 Specifications

General

Product color	Black
Recommended usage	DJ
Suitable for outdoor use	-
Tweeter	Yes
Speaker type	2-way
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Number of woofer drivers	2
Number of tweeter drivers	1
Woofer diameter (imperial)	15 \
Tweeter diameter (imperial)	1 \
Impedance	4 Ω
Sensitivity	100 dB
Frequency range	61 - 16000 Hz
RMS rated power	600 W
Equalizer	No
Connectivity technology	Wired

Weight and Dimensions

Depth	521 mm
Width	429 mm
Height	1044 mm
Weight	33500 g
