JBL SB130 User Manual

Key Board & LED board -- Circuit & Layout Diagram
8-1
8-1
REM
1
GND
2
Vcc
3
IR400
REMOTE
IR
C401
104
MCU_3.3V
L400
FB/1K
LED400
LED-R
LED401
LED-B
LED402
LED-O
94V0标志
R406
470
R407
47
R408
100
R409
100
R410
100
无铅标志
1
LED403
LED-W
LED404
LED-R
C402
10u
C403
10P
L401
FB/1K
1
2
3
4
5
6
7
8
9
10
CN401
1.5/10P
GND
IR
MCU_3.3V
LED4
LED5
LED1
LED2
LED3
LED4 LED5 LED1 LED2 LED3
ADKEY2
1
2
3
CN402
1.5/3P
GND
ADKEY1
MCU_3.3V
ADKEY1
ADKEY2
LED BOARD
CB301
104
SW300
VOL+
SW301
VOL-
SW302
EQ
R312
1K*
R311
62K*
ADKEY1
SW303
SRC
SW304
POWER
R314
27K*
1
2
3
CN301
1.5/3P
ADKEY1
GND
94V0标志
ADKEY2
无铅标志
1
ADKEY2
CB302
104
R310
15K*
R313
62K*
KEY BOARD

JBL SB130 Specifications

General

Power Output	110W
Bluetooth Version	4.2
HDMI ARC	Yes
Dolby Digital	Yes
Subwoofer	Yes
Type	Soundbar with wireless subwoofer
Channels	2.1
Optical Input	Yes
USB	No
Wall Mountable	Yes
Remote Control	Yes
Frequency Response	40Hz – 20kHz
Soundbar Dimensions (W x H x D)	900 x 67 x 63 mm
