11
88.10 mm
[3.47 in]
432.00 mm
[17.00 in]
401.00 mm
[15.79 in]
1
USB
VMA 260
4
1 2 3 MUSIC 1 4 5 6 MUSIC 2
MASTER 2MASTER 1
SIDE VIEW
FRONT VIEW
Figure 2.2.1 Dimensions
Front Angle Brackets
Rear Angle Brackets
Rear Flat Brackets
Figure 2.2.2 Mounting Kit
