15 - Engine
06 - Cylinder Head
00 - General
15 - 45 9813/7400-1 15 - 45
Remove and Install
Special Tools
Description Part No. Qty.
Torque Wrench
(10-100Nm)
993/70111 1
Consumables
Description Part No. Size
Cleaner/Degreaser
- General purpose
solvent based parts
cleaner
4104/1557 0.4L
Before Removal
1. This procedure requires service parts. Make sure
you have obtained the correct parts before you
start, refer to Parts Catalogue.
2. Make sure that the engine is safe to work on. If
the engine has been running, let it cool before
you start the service work.
3. Get access to the engine.
4. Remove the thermostat, refer to (PIL 21-12).
5. Remove the fuel pipes, refer to (PIL 18-96).
6. Remove the rocker cover, refer to (PIL 15-42).
7. Remove the fuel injectors, refer to (PIL 18-18).
8. Remove the rocker assembly, refer to (PIL
15-42).
9. Remove the exhaust manifold, refer to (PIL
18-24).
10. Remove the inlet manifold, refer to (PIL 18-24).
To Next Page
