Section 3-2 - Routine Maintenance
Service Schedules - Machines with SD and SF Engines
Pre-start Cold Checks, Service Points and Fluid Levels
3-2-4 3-2-4
9803/3750-05 (3-20-00)
Axle Mount Security - Check
Axle(s) Oil Level - Check
Axle(s) Oil - Change
Hub Oil Level (Without Oil Immersed Brakes) - Check
Hub Oil (Without Oil Immersed Brakes)
(9)
- Change
Hub Oil (With Oil Immersed Brakes)
(9)
- Change
Axle Breather(s) - Check
Trunnion Bearings
(7)
- Check/Adjust
Steering Stops (if fitted) - Security
Front Hub Bearings - Check
Wheel Nut Security - Check
Tyre Pressures/Condition - Check
Wheel Alignment - Check
Transmission Strainer - Clean
Drive Shafts and Universal Joints
(10)
- Security and Grease
Axle Pivots and Linkages
(10)
- Grease
HYDRAULICS
Oil Level - Check
Oil
(7)
- Sample, Change
Oil Filter
(11)
- Change
Suction Strainer - Clean
Pilot Filter (if fitted) - Change
BRAKES
Brake System Fluid Level - Check
Brake System Fluid - Change
Brake Plate Condition - Check
ELECTRICS
Battery Electrolyte Level (if applicable) - Check
Wiring for Chafing/Routing - Check
Battery Terminals for Condition and
Tightness
- Check
BODYWORK AND CAB
Operation 10 50
100
(1)
500 1000 2000 6000
