Section 1-5 - General Information
Service Tools
Numerical List
1-5-3 1-5-3
9803/3750-05 (1-06-00)
892/00822 Splined Bolt Socket K Fig 58. ( T 1-5-21)
892/00842 Glass Lifter K Fig 3. ( T 1-5-6)
892/00843 Folding Stand for Holding Glass K Fig 4. ( T 1-5-6)
892/00844 Long Knife K Fig 17. ( T 1-5-8)
892/00845 Cartridge Gun K Fig 5. ( T 1-5-6)
892/00846 Glass Extractor (Handles) K Fig 6. ( T 1-5-6)
892/00847 Nylon Spatula K Fig 7. ( T 1-5-6)
892/00848 Wire Starter K Fig 8. ( T 1-5-6)
892/00849 Braided Cutting Wire K Fig 9. ( T 1-5-7)
892/00881 Valve Spool Seal Fitting Tool K Fig 43. ( T 1-5-16)
892/00893 Torque Converter Alignment Tool K Fig 60. ( T 1-5-21)
892/00905 LMI Test Box K Fig 21. ( T 1-5-9)
892/00948 Nitrogen Charging Kit (without gauge) K Fig 48. ( T 1-5-17)
892/00949 Gauge K Fig 48. ( T 1-5-17)
892/00964 Test Point 1/8 BSP (Powershift) K Fig 40. ( T 1-5-16)
892/00965 Test Point 3/8 BSP (Powershift) K Fig 41. ( T 1-5-16)
892/01016 Ram Protection Sleeve for 25 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01017 Ram Protection Sleeve for 30 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01018 Ram Protection Sleeve for 40 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01019 Ram Protection Sleeve for 50 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01020 Ram Protection Sleeve for 50 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01021 Ram Protection Sleeve for 60 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01022 Ram Protection Sleeve for 60 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01023 Ram Protection Sleeve for 65 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01024 Ram Protection Sleeve for 70 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01025 Ram Protection Sleeve for 75 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01026 Ram Protection Sleeve for 80 mm Rod Diameter K Fig 53. ( T 1-5-20)
892/01027 Piston Seal Assembly Tool K Fig 56. ( T 1-5-20)
892/01174 Data Link Adaptor Kit K Fig 64. ( T 1-5-22)
892/01268 Digital Pressure Gauge 0-400 bar K Fig 45. ( T 1-5-16)
892/01271 Hose for Digital Pressure Gauge 892/01268 K Fig 45. ( T 1-5-16)
926/15500 Rubber Spacer Blocks K Fig 10. ( T 1-5-7)
992/01100 Glazing Tool K Fig 16. ( T 1-5-8)
992/04000 Torque Multiplier K Fig 57. ( T 1-5-21)
992/04800 Flange spanner K Fig 62. ( T 1-5-21)
992/09100 Spool Clamp K Fig 49. ( T 1-5-18)
992/09300 Hexagon Spanner 55 mm A/F K Fig 55. ( T 1-5-20)
Part
Number:
Description: Tool Detail Reference:
ProCarManuals.com

jcb 535-140 Hi Viz Specifications

General

Max Travel Speed	29 km/h
Width	2.35 m
Height	2.59 m
Maximum Lift Capacity	3500 kg
Engine Power	55 kW
Length	6.26 m
