jcb 540-170 Service Manual

Section 1-4 - General Information
Torque Settings
Zinc Plated Fasteners and Dacromet Fasteners
1-4-5 1-4-5
9803/3750-05 (1-05-00)
Table 6. Torque Settings - Rivet Nut Bolts/Screws
Table 7. Torque Settings - Internal Hexagon Headed Cap Screws (Zinc)
Bolt Size
Nm kgf m lbf ft
ISO Metric
Thread mm
M3 3 1.2 0.1 0.9
M4 4 3.0 0.3 2.0
M5 5 6.0 0.6 4.5
M6 6 10.0 1.0 7.5
M8 8 24.0 2.5 18.0
M10 10 48.0 4.9 35.5
M12 12 82.0 8.4 60.5
Bolt Size
Nm kgf m lbf ft
ISO Metric
Thread
M3 2.0 0.2 1.5
M4 6.0 0.6 4.5
M5 11.0 1.1 8.0
M6 19.0 1.9 14.0
M8 46.0 4.7 34.0
M10 91.0 9.3 67.0
M12 159.0 16.2 117.0
M16 395.0 40.0 292.0
M18 550.0 56.0 406.0
M20 770.0 79.0 568.0
M24 1332.0 136.0 983.0
