01 - Machine
09 - Description
12 - Main Component Locations
01 - 23 9813/8950-2 01 - 23
(For: 6T-1 Front Tip, 7T-1 Front Tip [Hi-Viz], 9T-1 Front Tip, Cab)
Figure 7.
G
A
F
E
J
C
B
A
D
H
A ROPS/FOPS/Cab B Beacons
C Engine D Tyres/ Wheels
E Steps F Head lights
G Skip H Mirrors
J Hand rails
