About the Product
Description
9 9831/5150-1 9
(For: JS20 MH [T4F])
Figure 4.
A
G
B
E
J
D
F
H
C
G
B
E
J
D
F
H
C
A Attachment ram B Dipper
C Dipper ram D Boom
E Operators cab F Cab ram
G Reversing fan control panel H Counterweight
J Stabilisers
