Power indication tag
(For example : In the case of 200V)
2-8-2. Connecting the power source cord
• Connecting 3-phase 200 to 240V
• Connecting single phase 100 to 120V
AC200 to 240V
Green/Yellow — GND
White
Black
Red
Power switch
Table
Never use under the wrong voltage and phase.
Rating plate
• Connecting single phase 220 to 240V
Green/Yellow — GND
AC220 to 240V
Light blue
Green/Yellow
Table
Control box
Power switch
Plug
Brown
White
Black
White
Black
Red
Table
Power switch
2-9. Installing the accessory ring core (Only for the EU type models)
2-9-1. Installing the accessory ring core supplied with the electrical box
Refer to accessory manual for "Installing the accessory ring core" supplied with the electrical box for
how to install the ring core.
After screwing the cable to
the power switch, bind the
cable sheath portion with
an accessory clip band
inside the power switch.
Green/Yellow
White
White
White
White
Black
Black
Black
Black
Red
Red
Green/Yellow
Control box
Green/Yellow
Control box
Green/Yellow
Green/Yellow
To Next Page
