26-4
Take-in of the data
① Display the communication screen.
When communication switch
(A)of
switch seat section is pressed in the data
input screen, the communication screen is
displayed.
② Select the communication procedure.
There are four communication procedures as
described below.
(B) Writing data from media to panel
(C) Writing data from personal computer
(server) to panel
(D) Writing data from panel to media
(E) Writing data from panel to personal
computer (server)
Select the button of communication procedure
you desire.
③ Select the data No.
When
(F)is pressed, the writing file
selection screen is displayed.
Input the file No. of the data you desire to
write. For the file No., input the numerals of
the part xxx of VD00xxx .vdt of the file name.
Designation of the pattern No. of writing
destination can be performed in the same way.
When the writing destination is the panel,
pattern Nos. which have not been registered
are displayed.
B
C
D
E
F
A
G
To Next Page
