JVC DR-MX10SE User Manual

1-2 (No.YD084)
SPECIFICATION
• Specifications shown are for SP mode unless otherwise specified.
• E.& O.E. Design and specifications subject to change without notice.
• Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
• "DTS" and "DTS DIGITAL OUT" are trademarks of Digital Theater Systems, Inc.
• This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright pro-
tection technology must be authorized by Macrovision. Reverse engineering or disassembly is prohibited.
• GUIDE Plus+, SHOWVIEW,VIDEO Plus+, G-LINK are (1) registered trademarks or trademarks of, (2) manufactured under license from and (3) subject of
various international patents and patent applications owned by, or licensed to, Gemstar-TV Guide International, Inc. and/or its related affiliates.
• GEMSTAR-TV GUIDE INTERNATIONAL, INC. AND/OR ITS RELATED AFFILIATES ARE NOT IN ANY WAY LIABLE FOR THE ACCURACY OF THE
PROGRAM SCHEDULE INFORMATION PROVIDED BY THE GUIDE PLUS+ SYSTEM. IN NO EVENT SHALL GEMSTAR-TV GUIDE INTERNATIONAL,
INC. AND /OR ITS RELATED AFFILIATES BE LIABLE FOR ANY AMOUNTS REPRESENTING LOSS OF PROFITS, LOSS OF BUSINESS, OR INDI-
RECT, SPECIAL, OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE PROVISION OR USE OF ANY INFORMATION, EQUIPMENT, OR
SERVICES RELATING TO THE GUIDE PLUS+ SYSTEM.
• i-LINK is a trademark of Sony Corp.
DR-MX10SEK DR-MX10SE DR-MX10SEF
GENERAL
Power requirement AC 220 V - 240 V, 50 Hz / 60 Hz
Power consumption
Power on 45 W
Power off 6.7 W
Temperature
Operating 5
°C to 35°C
Storage -20
°C to 60°C
Operating position Horizontal only
Dimensions (W
× H × D) 435 mm × 96 mm × 384 mm
Weight 6.9 kg
VIDEO/AUDIO (DVD Deck)
Recordable disc DVD-RAM 12 cm (4.7 GB/9.4 GB*1), DVD-RAM 8 cm (1.4 GB/2.8 GB*2), DVD-R 12 cm (4.7 GB)
DVD-R 8 cm (1.4 GB), DVD-RW 12 cm (4.7 GB), DVD-RW 8 cm (1.4 GB)
*1 9.4 GB double-sided discs *2 2.8 GB double-sided discs
Recording format DVD-RAM : DVD Video Recording format
DVD-R : DVD Video format, DVD Video Recording format
DVD-RW : DVD Video format, DVD Video Recording format
Recording time Maximum 8 hours (with 4.7 GB disc)
(XP): Approx. 1 hour, (SP): Approx. 2 hours, (LP): Approx. 4 hours
(EP): Approx. 6 hours, (FR): Approx. 1 hour - 8 hours
Audio recording system Dolby Digital (2 ch), Linear PCM (XP mode only)
Video recording compression system MPEG2 (CBR/VBR)
VIDEO/AUDIO (HDD Deck)
Capacity 160 GB
Recording time (DV) : Approx. 11 hours, (XP) : Approx. 34 hours, (SP) : Approx. 69 hours
(LP) : Approx. 138 hours, (EP) : Approx. 209 hours, (FR480) : Approx. 300 hours
Audio recording system Dolby Digital (2 ch), Linear PCM (XP mode only)
Video recording compression system MPEG2 (VBR)
VIDEO/AUDIO (VHS Deck)
Signal system PAL colour signal and CCIR monochrome signal, 625 lines / 50 fields
Recording system DA4 (Double Azimuth) head helical scan system
Format VHS PAL standard
Maximum recording time
(SP) 240 min. with E-240 video cassette
(LP) 480 min. with E-240 video cassette
Signal-to-noise ratio 45 dB
Horizontal resolution 230 lines
Frequency range 70 Hz to 10,000 Hz (Normal audio) 20 Hz to 20,000 Hz (Hi-Fi audio)
INPUT/OUTPUT
21-pin SCART connectors IN / OUT
× 1, IN / DECODER × 1
S-video input Y: 1.0 Vp-p, 75 Ω, C: 0.3 Vp-p, 75 Ω
Video input 1.0 Vp-p, 75 Ω (pin jack)
Audio input 2 Vrms (pin jack)
i.Link 4-pin for DV Input/Output
Component video output
Y: 1.0 Vp-p, 75 Ω, Pb/Pr: 0.7 Vp-p, 75 Ω Corresponding to copy protection
Digital audio output Coaxial
Corresponding to Dolby Digital and DTS Digital Surround,
Bit stream Selectable in digital audio output setting menu
G-LINK Ø3.5 mm jack
TUNER/TIMER
Tuning system Frequency synthesized tuner
Signal system PAL colour signal, 625 lines/50 fields PAL/SECAM colour signal, 625 lines/50 field
TV channel storage capacity 99 positions (+AUX position)
Channel coverage (PAL B/G)
VHF : 44.5 MHz - 143 MHz/143 MHz - 470
MHz
UHF : 470 MHz - 862 MHz
VHF : 47 MHz - 89 MHz/104 MHz - 300
MHz/302 MHz - 470 MHz
UHF : 470 MHz - 862 MHz
VHF(LOW) : 47MHz-89MHz(E2-E4,X,Y,Z)
VHF(HIGH) : 104MHz-300MHz(E5 - E12,
S1-S20, M1 - M10, U1 - U10)
Hyper: 302MHz - 470MHz (S21-S41)
UHF: 470MHz - 862MHz (E21 - E69)
Channel coverage(SECAM-L)
-
VHF(LOW) : 49MHz - 65MHz (2-4)
VHF(HIGH) : 104MHz-300 MHz(5-10,CATV)
Hyper : 300MHz - 470MHz (CATV)
UHF : 470MHz - 862MHz (21 - 69)
Clock reference Quartz
Memory backup time Approx. 10 minutes
