GETTING STARTED
8
EN
MasterPage: Left
Controls
1
Rewind Button [
1
] (
pg. 20)
Left Button [
1
] (
pg. 14)
Quick Review Button [QUICK REVIEW]
(
pg. 19)
2
Set Button [SET] (
pg. 14)
Data Battery Button [DATA] (
pg. 12)
3
Stop Button [
7
] (
pg. 20)
Backlight Compensation Button
[BACKLIGHT] (
pg. 28)
Down Button [
4
] (
pg. 22)
4
Play/Pause Button [
6
] (
pg. 20)
Manual Focus Button [FOCUS] (
pg. 27)
Up Button [
3
] (
pg. 22)
5
Wide 16:9 Button [16:9] (
pg. 26)
Blank Search Button [BLANK] (
pg. 20)
6
Menu Button [MENU] (
pg. 22)
7
Fast-Forward Button [
¡
] (
pg. 20)
Right Button [>] (
pg. 14)
Night Button [NIGHT] (
pg. 26)
8
Diopter Adjustment Control (
pg. 15)
9
Auto Button [AUTO] (
pg. 13)
!
Snapshot Button [SNAPSHOT] (
pg. 26)
"
Power Zoom Lever [T/W] (
pg. 18)
Speaker Volume Control [VOL. +, –]
(
pg. 20)
#Battery Release Button [PUSH BATT.]
( pg. 11)
$Recording Start/Stop Button ( pg. 17)
%Power Switch [REC, OFF, PLAY] ( pg. 13)
&Lock Button ( pg. 13)
(Cassette Open/Eject Switch [OPEN/EJECT]
( pg. 16)
Connectors
The connectors are located beneath the covers.
á
Audio/Video Output Connector [AV]
( pg. 21, 32)
à
DC Input Connector [DC] ( pg. 11)
â
Digital Video Connector [DV IN/OUT] (i.LINK*)
( pg. 33, 34)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo
is used for products compliant with the i.LINK
standard.
Indicators
ä
POWER/CHARGE Lamp ( pg. 11, 17)
Other Parts
ã
LCD Monitor ( pg. 18, 19)
å
Viewfinder ( pg. 15)
ç
Battery Pack Mount ( pg. 12)
é
Shoulder Strap Eyelet ( pg. 11)
è
Speaker ( pg. 20)
ê
Grip Strap ( pg. 14)
ë
Lens
í
Camera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
ì
Stereo Microphone
î
Stud Hole ( pg. 15)
ï
Tripod Mounting Socket ( pg. 15)
ñ
Cassette Holder Cover ( pg. 16)
GR-D347US_EN.book Page 8 Wednesday, July 12, 2006 3:51 PM
