1 Remote Sensor
The transmitted beam’s approximate effective
distance for indoor use is 5m (16ft).
The transmitted beam may not be effective or may
cause incorrect operation outdoors or when the
remote sensor is directly exposed to sunlight or
powerful lighting.
Camera Sensor
Be careful not to cover this area, a sensor
necessary for shooting is built-in here.
2 Grip Strap .................................................... pg. 8
3 Tally Lamp ........................................... pg. 12, 30
4 VIDEO/DSC Switch [VIDEO, DSC] ........... pg. 13
5 Stop Button [5] ......................................... pg. 14
6 Rewind Button [
2
] .................................. pg. 14
7 Play/Pause Button [
4
/6] ........................... pg. 14
8 Fast-Forward Button [
3
] ......................... pg. 14
9 USB (Universal Serial Bus) Connector ...... pg. 40
0 INFO Button ............................................ pg. 19
NIGHT Button .......................................... pg. 23
! INDEX Button .......................................... pg. 19
BACKLIGHT Button................................. pg. 26
@ Digital Video Connector [DV] (i.Link*) ... pg. 34, 40
* i.Link refers to the IEEE1394-1995 industry
specification and extensions thereof. The logo is
used for products compliant with the i.Link
standard.
# Battery Pack Mount ..................................... pg. 7
$ DC Input Connector .................................... pg. 7
% MENU Wheel [+, –] ................................. pg. 28
Speaker Volume Control [VOLUME]........ pg. 14
^ Snapshot Button [SNAPSHOT] ........... pg. 17, 25
& Power Zoom Lever [T/W] ........................... pg. 13
* FOCUS Button ........................................ pg. 26
BLANK SEARCH Button ......................... pg. 15
( Audio/Video Input/Output Connector
[AV] ...................................................... pg. 16, 33
) Edit Connector [EDIT] ............................... pg. 37
q S-Video Input/Output Connector
[S-VIDEO] ........................................... pg. 16, 33
w Diopter Adjustment Control ......................... pg. 8
e Recording Start/Stop Button ..................... pg. 12
r Shoulder Strap Eyelets ............................... pg. 9
t POWER/CHARGE Lamp ................ pg. 7, 12, 13
y Lock Button ............................................... pg. 13
u Power Switch
[ , , PLAY, OFF (CHARGE)] .............. pg. 13
i Monitor Open Button ................................. pg. 12
o Stud Hole .................................................... pg. 9
p Tripod Mounting Socket .............................. pg. 9
Q MEMORY CARD Cover ............................ pg. 11
W Battery Release Button [BATT. RELEASE] .... pg. 7
E OPEN/EJECT Switch .................................. pg. 9
R Infrared Beam Transmitting Window
Transmits the beam signal.
T Zoom (W) Button ................................. pg. 13, 35
Y Zoom (T) Button .................................. pg. 13, 35
U DISPLAY Button .................................. pg. 16, 33
I SHIFT Button ...................................... pg. 35, 36
O SLOW Button [
0
] .................................... pg. 35
Right Button ............................................ pg. 35
P SLOW Button [
9
] .................................... pg. 35
Left Button ............................................... pg. 35
a REW Button*
s FADE/WIPE Button ................................... pg. 37
d EFFECT ON/OFF Button .......................... pg. 35
f EFFECT Button ......................................... pg. 35
g EDIT IN/OUT Button .................................. pg. 37
h CANCEL Button ........................................ pg. 37
j PAUSE IN Connector ................................ pg. 37
k START/STOP Button*
l MBR SET Button ....................................... pg. 36
; Snapshot Button* [SNAPSHOT]
A Up Button ................................................ pg. 35
INSERT Button ........................................ pg. 39
S Down Button ............................................ pg. 35
A. DUB Button ......................................... pg. 39
D PLAY Button*
F FF Button*
G STOP Button*
H PAUSE Button*
J R.A.EDIT ON/OFF Button ................... pg. 37, 38
K VCR REC STBY Button ............................ pg. 38
The connectors ), q are located beneath a cover.
* Functions the same as each corresponding button on
the camcorder.
