B5A-1103-00
2
© 2015 JVC KENWOOD Corporation
[Adaptive Bit Rate] and [PCR Jitter] added to menu item (K)
The following items are added to [System]
N
[Network]/[Settings]
N
[Live
Streaming Set]
N
[Streaming Server]
N
[Server1] / [Server2] / [Server3] /
[Server4].
● Adaptive Bit Rate:
If “On” is selected, the bit rate setting value of live streaming is set to
maximum limit, and the bit rate is changed automatically according
to changes in the network bandwidth. [Setting Values: On,
ROff]
● Adaptive bit rate setting is possible only when [Type] is set to “ZIXI” and
[Latency] is set to either “Medium” or “Low”.
* The bit rate is displayed on the status screen only when “On” is set.
● PCR Jitter:
Setting to “Low” reduces to PCR jitter of live streaming.
[Setting Values:
RNormal, Low]
● This item is selectable only when [Type] is set to “MPEG2-TS/UDP”.
[APN] added to menu item (K)
[APN] is added to [System]N[Network] / [Settings]N[Connection
Setup].
* APN: Access Point Name
* This item is gray out and cannot be selected if APN cannot be set for
the adapter attached.
● The APN setting is written into the cellular adapter, not this camera
recorder. Setting a wrong APN may result in communication failure or
expensive bills from the telecommunications company. Set the APN
correctly.
FTP resume feature added (K)
When FTP transfer starts and there is a file of the same name on the
server with a file size smaller than the file to be transferred, the file on
the server will be regarded as an interrupted file during a FTP transfer.
A confirmation screen to resume transfer (append writing) appears.
If “Resume” is selected, FTP transfer is carried out such that it appends
from the position where it was interrupted. When FTP transfer ends
normally, “Successfully Completed.” appears on the screen.
● FTP server equipped with resume function is required.
● If [System]N[Network] / [Settings]N[Clip Server]N[Clip-FTP1/2/3/4]N
[Protocol] is set to “SFTP”, the “Resume” function is disabled.
● If “HTTP” is selected in the [Select FTP Proxy] screen of the network
connection setting, the resume function is disabled.
Setting value “ZIXI” added to menu item [Protocol] (K)
“ZIXI” is added to [System]N[Network] / [Settings]N[Clip Server]N
[Clip-FTP1/2/3/4]N[Protocol].
If “ZIXI” is selected, [Username] in [System]
N
[Network] / [Settings]
N
[Clip Server]
N
[Clip-FTP1/2/3/4] changes to [Stream ID].
[Setting Values:
R
FTP, SFTP, FTPS, FTPES, ZIXI]
● To use the “ZIXI” setting, a dedicated server is needed separately.
● If “ZIXI” is set, the “Resume” function is enabled.
Items added to thumbnail screen
The following items are added to the metadata display on the detailed
screen of the thumbnail screen.
● Clip Size
● Gamma
Clip Continuous added to recording mode for AVCHD
“Clip Continuous” is added to the setting value for “AVCHD” format in
[System]N[Record Set]N[Rec Mode].
Clip Continuous Rec can also be operated in “AVCHD” mode.
Setting value “Side Cut” added to menu item [SD Aspect]
“Side Cut” is added to the setting value for [A/V Set]N[Video Set]N
[SD Aspect].
● Letter:
Displays as a wide image with the top and bottom blackened.
● Squeeze:
Displays image that is squeezed horizontally.
● Side Cut:
Displays wide screen with the left and right sides cut off.
[Setting Values:
RSqueeze, Letter, Side Cut]
● When “SD” is selected in [System]N[Record Set]N[Record Format]N
[System], “Squeeze” and “Letter” can be selected.
2.5x display mode added to Expanded Focus function in 4K mode
An approximately 2.5x display mode is added to the Expanded Focus
function when “4K” is selected in [System]N[Record Set]N[Record
Format]N[System]. You can use the Set button (
R) to switch between
the conventional dot by dot equivalent (approximately 5x) display and
the 2.5x display.
● Upon power on, the display of the initial Expanded Focus is dot by dot
equivalent (approximately 5x).
[Camera Data] added to menu item
[Camera Data] is added to [LCD / VF]N[Display Settings].
● Always:
The Iris F-number, Gain, Shutter and White Balance values are
always displayed. The [A] icon appears on the left of the value when
in the Auto mode.
● Manual Only:
The Iris F-number, Gain, Shutter and White Balance values are
displayed only in Manual mode.
[Setting Values: Always,
RManual Only]
Setting for operating Iris/Shutter/AE Level using iris dial added
Setting value “Iris/Shutter/AE Level” are added to [Camera Function]
N
[Iris Dial].
If “Iris/Shutter/AE Level” is selected, the iris dial that is normally used to
operate the iris will operate the shutter when the [SHUTTER] button is
pressed and will operate the AE level when the [AE LEVEL] button is
pressed. After which, the iris dial resumes its iris operation.
[Setting Values:
RIris, Shutter, AE Level, Iris/Shutter/AE Level]
[HDMI TC] added to menu item
[HDMI TC] is added to [A/V Set]N[Video Set].
For setting whether to superimpose the time code to the HDMI output
terminal.
[Setting Values:
ROff, On]
● When [A/V Set]N[Video Set]N[HDMI/SDI Out] is set to “SDI” or “Off”,
[HDMI TC] is fixed at “Off” and selection is disabled. (K)
● When [A/V Set]N[Video Set]N[HDMI Out] is set to “Off”, [HDMI TC] is
fixed at “Off” and selection is disabled. (M)
●
Set to “Off” when connecting to a device that does not support HDMI TC.
Setting value changed in [Resolution] under [HDMI/SDI Out]
(
K) and [HDMI Out] (M)
The video output is changed to native frame rate and setting values are
added. For selecting the resolution of video output from the [HDMI]
terminal or [SDI OUT] terminal according to the monitor to be connected.
[Setting Values: 576i, 576p, 480i, 480p, 720p, 1080i, 1080p, 1080/30p,
1080/25p, 1080/24p, 2160/24p, 2160/25p, 2160/30p]
Other notes
●
The “MPEG LA MPEG-2 Patent” described in the “INSTRUCTIONS”
of this book is not applicable to this product.
Manufacturer
3-12, Moriya-cyo, Kanagawa-ku, Yokohama-shi,
Kanagawa 221-0022, Japan
