JVC KD-DV5100 Service Manual

3-10
C175 NCB31HK-471X C CAPACITOR 470pF 50V K
C176 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C177 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C181 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C182 QTE1H55-225Z E CAPACITOR 2.2uF 50V
C184 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C185 NCB31HK-471X C CAPACITOR 470pF 50V K
C186 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C187 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C301 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C302 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C311 NBE21CM-475X TA E CAPACITOR 4.7uF 16V M
C312 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C313 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C314 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C315 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C316 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C328 NFV81CM-105X MF CAPACITOR 1uF 16V M
C329 NCS31HJ-101X C CAPACITOR 100pF 50V J
C331 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C338 NFV81CM-105X MF CAPACITOR 1uF 16V M
C339 NCS31HJ-101X C CAPACITOR 100pF 50V J
C346 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C348 NFV81CM-105X MF CAPACITOR 1uF 16V M
C349 NCS31HJ-101X C CAPACITOR 100pF 50V J
C356 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C358 NFV81CM-105X MF CAPACITOR 1uF 16V M
C359 NCS31HJ-101X C CAPACITOR 100pF 50V J
C401 NCS31HJ-220X C CAPACITOR 22pF 50V J
C402 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C403 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C404 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C405 NCS31HJ-220X C CAPACITOR 22pF 50V J
C406 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C411 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C412 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C413 QCZ0202-155Z C CAPACITOR 1.5uF 25V Z
C414 QERF0JM-337Z E CAPACITOR 330uF 6.3V M
C415 NCS31HJ-101X C CAPACITOR 100pF 50V J
C416 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C701 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C702 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C703 NDC31HJ-101X C CAPACITOR 100pF 50V J
C704 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C705 NDC31HJ-101X C CAPACITOR 100pF 50V J
C721 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C722 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C723 NCS31HJ-471X C CAPACITOR 470pF 50V J
C724 NCS31HJ-471X C CAPACITOR 470pF 50V J
C725 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C726 NDC31HJ-8R0X C CAPACITOR 8pF 50V J
C727 NDC31HJ-270X C CAPACITOR 27pF 50V J
C728 NDC31HJ-270X C CAPACITOR 27pF 50V J
C729 NDC31HJ-220X C CAPACITOR 22pF 50V J
C730 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C731 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C732 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C733 NCS31HJ-471X C CAPACITOR 470pF 50V J
C781 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C783 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C802 NCS31HJ-220X C CAPACITOR 22pF 50V J
C803 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C804 NCS31HJ-220X C CAPACITOR 22pF 50V J
C821 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C822 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C823 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C881 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C885 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C901 QEZ0722-338 E CAPACITOR 3300uF
C902 QEKJ1HM-225Z E CAPACITOR 2.2uF 50V M
C903 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C905 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C906 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C907 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C908 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C909 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
C910 NCB31HK-102X C CAPACITOR 1000pF 50V K

Symbol
No.
Part No. Part Name Description Local
C911 NCB31HK-102X C CAPACITOR 1000pF 50V K
C912 QEKJ1CM-226Z E CAPACITOR 22uF 16V M
C913 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C921 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C922 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C925 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C926 QEXL1AM-476Z E CAPACITOR 47uF 10V M
C927 QEZ0595-477Z E CAPACITOR 470uF
C928 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C929 NCB31HK-472X C CAPACITOR 4700pF 50V K
C930 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C961 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C962 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C963 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C964 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C965 QEKJ1AM-227Z E CAPACITOR 220uF 10V M
C966 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C967 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C968 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C969 NCB31EK-473X C CAPACITOR 0.047uF 25V K
C981 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C997 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C999 NCS31HJ-101X C CAPACITOR 100pF 50V J
R1 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R2 NRS181J-220X MG RESISTOR 22
Ω 1/8W J
R3 NRS181J-220X MG RESISTOR 22
Ω 1/8W J
R4 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R5 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R6 NRSA63J-332X MG RESISTOR 3.3k
Ω 1/16W J
R7 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R8 NRS181J-0R0X MG RESISTOR 0
Ω 1/8W J
R9 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R12 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R14 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R31 NRSA63J-470X MG RESISTOR 47
Ω 1/16W J
R32 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R33 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R34 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R35 NRSA63J-393X MG RESISTOR 39k
Ω 1/16W J
R36 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R37 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R38 NRSA63J-100X MG RESISTOR 10
Ω 1/16W J
R39 NRSA63J-622X MG RESISTOR 6.2k
Ω 1/16W J
R40 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R42 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R43 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R44 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R52 NRSA63J-273X MG RESISTOR 27k
Ω 1/16W J
R81 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R82 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R91 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R92 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R101 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R102 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R103 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R104 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R105 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R106 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R107 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R111 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R112 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R113 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R114 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R115 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R116 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R117 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R141 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R151 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R155 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R161 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R162 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R163 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R164 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R166 NRSA63J-221X MG RESISTOR 220
Ω 1/16W J
R167 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J

Symbol
No.
Part No. Part Name Description Local
