1-6 (No.49793)
2.1.2 Removing the front panel assembly
(See Fig.6~8)
• Prior to performing the following procedure, remove the top
chassis assembly.
(1) Disconnect the flexible harness from connector CN701 on
the main board assembly.
(2) Remove the four screws H attaching the front panel as-
sembly on both sides of the body. Remove the front panel
toward the front.
Fig.6
Fig.7
Fig.8
CN701
Front panel assembly
H
Front panel assembly
H
Front panel assembly
CN701
