2009 JVC Product Tech Guide
C M Y K
KD-R300
KD-R300
CD Receiver with Front AUX
Maximum Power Output 50W x 4
Continuous Power Output (RMS) 20W RMS x 4 Channels at 4Ω ;
* Total Harmonic Distortion 1.0% THD* + N
Line Preoput Terminals (Pair) 1 pair (Rear/Subwoofer Selectable)
Subwoofer Output with
Level/Frequency Control
✔ (Rear/Subwoofer Selectable)
Line Output Level 2.5V
Subwoofer Output Level 2.5V
Subwoofer Gain Control 0 - 16dB
Load Impedance 4Ω (4 - 8Ω allowable)
Line Output Impedance 1kΩ
Dimentions (W x H x D)
Installation Size 7
3/16
” x 2
1/16
” x 6
5/16
” 182 x 52 x 159.5 mm
Panel Size 7
7/16
” x 2
5/16
” x
1/4
” 188 x 58 x 5.6 mm
Detachable Face Plate 6
3/4
” x 1
13/16
” x
3/4
” 170 x 46 x 18.8 mm
Key Specifications
SAT Radio Ready
Compatible with XM/Sirius Satellite Radio.
(separate tuners required)
KS-BTA200
(optional)
Cell phone
Ready for Bluetooth
®
Adapter
Bluetooth
®
Wireless Technology is available with an optional adapter (KS-BTA200)*,
for hands-free calling and audio streaming.
* Not available in some countries. Available functions depend on the cell phone.
MOS-FET Power Amp
Enables highly faithful sound reproduction with
distortion-free pure signal preout.
MOS-FET
50W x 4
Front AUX Input
Easy connection for digital audio players and
other devices.
NTK-9520-04
Ready for iPod Adapter (Ready for KS-PD100)
With an optional KS-PD100 adapter,
you can connect and control your iPod
on the headunit.
iPod
KS-PD100
(optional)
KS-BTA200
KT-HD300
Connections
Portable Audio Players
J-BUS
AUX-IN
KS-PD100
iPod
HD Radio
®
Ready
HD Radio
®
available with an
optional KT-HD300 tuner.
KT-HD300
* With J-BUS connection, KS-PD100 may hang up while using iPod nano 2nd generation.
** iPod battery will not be charged via connection with KS-PD100.
Compatible iPod/iPhone Models
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
Requires
KS-PD100
* **
