13
STEERING
WHEEL
REMOTE
KD-R647 KD-R641 / KD-R547 / KD-R541 /
KD-R449
Light blue/yellow
KD-R641
only
Wiring connection
Signal cord
(not supplied)
Remote wire
(not supplied)
Rear ground terminal
To the steering wheel remote control adapter
Fuse (10 A)
To Blue/white
wire of the wiring
harness
D
Aerial terminal
(Not available for
KD-R447
/
KD-R443
/
KD-R442
/
KD-R441
)
JVC Amplifier
Part list for installation
( ×2 )
( ×1 )
( ×1 )
( ×1 )
( ×1 )
A
Faceplate
B
Mounting sleeve
C
Trim plate
D
Wiring harness
E
Extraction key
Front output
Rear/subwoofer output Rear/subwoofer output
IMPORTANT: A custom wiring harness (separately
purchased) which is suitable for your car is
recommended for connection.
If your car has an ISO terminal
If your car does NOT have an ISO terminal
( or )
( or )
ISO connector
* Custom wiring harness (separately purchased)
For some VW/Audi or Opel (Vauxhall)
automobiles
You may need to modify the wiring of the supplied
power cord
D
as illustrated.
If the unit does not turn on with modified wiring 1,
use modified wiring 2 instead.
Y: Yellow R: Red
Original wiring
Modified wiring 1
Modified wiring 2
B1/B2
Purple
ª
/ Purple/black
·
:
Rear speaker (right)
B3/B4
Gray
ª
/ Gray/black
·
:
Front speaker (right)
B5/B6
White
ª
/ White/black
·
:
Front speaker (left)
B7/B8
Green
ª
/ Green/black
·
:
Rear speaker (left)
A2
To mobile phone system
(Brown)
A4 Yellow: Battery
A5 Blue/white: Remote wire
A6
Orange/white: Car light control
switch
A7 Red: Ignition (ACC)
A8
Black: Earth (ground)
connection
ENGLISH
EN_KD-R647[E_EE]001A_f.indd 13EN_KD-R647[E_EE]001A_f.indd 13 2/27/13 9:20:41 AM2/27/13 9:20:41 AM
