3-3
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GE10043-210A TOP CHASSIS
2 GE40135-001A EARTH PLATE
3 GE30938-003A SIDE PANEL
4 GE30393-002A BOTTOM COVER
5 FSMA3004-203 INSULATOR
6 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
7 FSKZ4005-001 SCREW (x2)
8 QYSDST2604Z SCREW 2.6mm x 4mm(x3)
9 QYSDST2606Z SCREW 2.6mm x 6mm(x2)
10 QYSDST2610Z SCREW 2.6mm x 10mm
11 GE10056-001A FRONT CHASSIS
12 GE30583-001A LOCK LEVER
13 FSKW4005-003 TORSION SPRING
14 FSXP3026-002 RLS KNOB
15 GE30999-002A COMP.SPRING
16 GE40140-002A BLIND
17 QYSDST2004M MINI SCREW 2mm x 4mm
18 GE10037-003A FRONT PANEL
19 GE30300-032A FINDER ASSY
20 GE20119-001A PRESET BUTTON
21 GE30304-001A POWER BUTTON
22 GE30305-001A EJECT BUTTON
23 GE20131-302A D.FUNC BUTTON
24 GE30307-001A SND.FUNC.BUTTON
25 GE20130-302A PUSH BUTTON
26 GE20118-002A +/- BUTTON
27 GE20120-001A UP/DOWN BUTTON
28 GE30306-001A DETACH BUTTON
29 FSKW3002-012 COMP.SPRING
30 GE30117-001A LIGHT LENS
31 GE10055-003A REAR COVER
32 VKZ4777-001 MINI SCREW (x4)
33 GE30302-003A LCD CASE
34 GE31101-001A LCD LENS
35 GE31102-001A LENS CASE
36 GE40213-001A LIGHTING SHEET
37 GE31074-001A NAME PLATE
38 LV41843-002A LASER CAUTION
39 QLD0292-001 LCD MODULE
40 QNZ0442-001 LCD CONNECTOR
41 QMFZ047-150-T FUSE 15A
42 GE40172-004A IC BRACKET
43 GE40124-002A REG BRACKET
44 QYSDST2606Z SCREW 2.6mm x 6mm
45 QYSDSF2606Z SCREW 2.6mm x 6mm
46 QYSDST2606Z SCREW 2.6mm x 6mm
47 QYSDSF2606Z SCREW 2.6mm x 6mm(x2)
48 GE30912-008A REAR BRACKET
49 GE30854-001A LED HOLDER
To Next Page
