KD-S8R

3-9

Item

Parts number Parts name Area

Electrical parts list

Remarks

Block No. 01

Item

Parts number Parts name Area

Remarks

C 1 NDC21HJ-5R0X C CAPACITOR

C 2 NDC21HJ-100X C CAPACITOR

C 3 QERF1HM-104Z E CAPACITOR .10MF 20% 50V

C 4 NCS21HJ-221X C CAPACITOR

C 5 QERF1HM-474Z E CAPACITOR .47MF 20% 50V

C 6 NCB21EK-473X C CAPACITOR

C 7 NCS21HJ-101X C CAPACITOR

C 9 QER41AM-227 E CAPACITOR 220MF 20% 10V

C 10 NCB21HK-102X C CAPACITOR

C 31 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 32 NCB21HK-102X C CAPACITOR

C 41 NCB21HK-333X C CAPACITOR

C 42 NCB21HK-822X C CAPACITOR

C 43 QERF1CM-107Z E CAPACITOR 100MF 20% 16V

C 44 NCB21HK-103X C CAPACITOR

C 51 QERF1HM-474Z E CAPACITOR .47MF 20% 50V

C 52 NCB21HK-472X C CAPACITOR

C 53 NCB21EK-104X C CAPACITOR

C 54 NCB21HK-103X C CAPACITOR

C 55 NCB21HK-331X C CAPACITOR

C 71 NDC21HJ-820X C CAPACITOR

C 72 NDC21HJ-470X C CAPACITOR

C 73 NCB21HK-103X C CAPACITOR

C 74 QERF1AM-476Z E CAPACITOR 47MF 20% 10V

C 75 NCS21HJ-561X C CAPACITOR

C 76 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 77 NCB21EK-223X C CAPACITOR

C 161 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 162 NCB21HK-822X C CAPACITOR

C 163 NCB21CK-154X C CAPACITOR

C 164 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 165 NCB21HK-333X C CAPACITOR

C 166 NCB21HK-562X C CAPACITOR

C 167 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 168 QEKJ1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 169 QERF1HM-105ZM E CAPACITOR 1.0MF 20% 50V

C 171 QERF1HM-105ZM E CAPACITOR 1.0MF 20% 50V

C 172 NCB21HK-183X C CAPACITOR

C 173 NCB21EK-104X C CAPACITOR

C 181 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 182 NCB21HK-822X C CAPACITOR

C 183 NCB21CK-154X C CAPACITOR

C 184 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 185 NCB21HK-333X C CAPACITOR

C 186 NCB21HK-562X C CAPACITOR

C 187 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 188 QERF1HM-225Z E CAPACITOR 2.2MF 20% 50V

C 189 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 191 QERF1HM-105ZM E CAPACITOR 1.0MF 20% 50V

C 192 NCB21HK-183X C CAPACITOR

C 241 QEKJ1HM-224Z E CAPACITOR .22MF 20% 50V

C 242 NCB21EK-473X C CAPACITOR

C 243 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 244 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 309 QERF1CM-106ZM E CAPACITOR 10MF 20% 16V

C 310 QERF1CM-106ZM E CAPACITOR 10MF 20% 16V

C 312 NCB21EK-473X C CAPACITOR

C 313 NCB21EK-104X C CAPACITOR

C 314 NCB21EK-104X C CAPACITOR

C 315 NCB21EK-104X C CAPACITOR

C 322 NCS21HJ-391X C CAPACITOR

C 332 NCS21HJ-391X C CAPACITOR

C 342 NCS21HJ-391X C CAPACITOR

C 352 NCS21HJ-391X C CAPACITOR

C 501 QERF1AM-227ZM E CAPACITOR 220MF 20% 10V

C 502 NCB21HK-103X C CAPACITOR

C 503 QEKJ1CM-226Z E CAPACITOR 22MF 20% 16V

C 521 NCB21HK-103X C CAPACITOR

C 522 NCB21HK-103X C CAPACITOR

C 523 NCB21EK-103X C CAPACITOR

C 524 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 525 NCB21HK-103X C CAPACITOR

C 526 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 527 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 528 NCS21HJ-101X C CAPACITOR

C 529 NCB21HK-103X C CAPACITOR

C 530 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 531 NCB21EK-104X C CAPACITOR

C 532 NCB21EK-104X C CAPACITOR

C 533 NCS21HJ-560X C CAPACITOR

C 541 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 542 NCB21HK-103X C CAPACITOR

C 543 QEKJ1HM-105Z E CAPACITOR 1.0MF 20% 50V

C 544 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 545 NCB21HK-103X C CAPACITOR

C 546 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 547 NDC21HJ-470X C CAPACITOR

C 548 NCB21HK-153X C CAPACITOR

C 549 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 550 NCB21HK-103X C CAPACITOR

C 551 NCB21HK-272X C CAPACITOR

C 552 NCB21HK-103X C CAPACITOR

C 553 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 554 NCB21HK-103X C CAPACITOR

C 555 NCB21EK-333X C CAPACITOR

C 556 NCB21HK-332X C CAPACITOR

C 557 NCS21HJ-561X C CAPACITOR

C 558 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 559 NCB21HK-473X C CAPACITOR

C 560 NCB21HK-473X C CAPACITOR

C 561 NCB21HK-473X C CAPACITOR

C 562 NCB21HK-473X C CAPACITOR

C 563 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 564 NCB21HK-103X C CAPACITOR

C 565 NCB21HK-103X C CAPACITOR

C 566 NDC21HJ-100X C CAPACITOR

C 567 NDC21HJ-100X C CAPACITOR

C 568 NCB21HK-103X C CAPACITOR

C 569 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 570 NCS21HJ-101X C CAPACITOR

C 571 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 572 QEKJ0JM-107Z E CAPACITOR 100MF 20% 6.3V

C 573 NCB21HK-103X C CAPACITOR

C 581 NCS21HJ-821X C CAPACITOR

C 582 QEKF1EM-475ZM E CAPACITOR 4.7MF 20% 25V

C 583 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 584 NCS21HJ-121X C CAPACITOR

C 591 NCS21HJ-821X C CAPACITOR

C 592 QEKF1EM-475ZM E CAPACITOR 4.7MF 20% 25V

C 593 QEKJ0JM-476Z E CAPACITOR 47MF 20% 6.3V

C 594 NCS21HJ-121X C CAPACITOR

C 595 QEKJ1AM-107Z E CAPACITOR 100MF 20% 10V

C 701 NDC21HJ-220X C CAPACITOR

C 702 NDC21HJ-220X C CAPACITOR

C 703 NCB21EK-104X C CAPACITOR

C 704 NCB21EK-104X C CAPACITOR

( Main board )
