1-2 (No.MB207)
SPECIFICATION
Design & specifications are subject to change without notice.
Amplifier section
Output Power MAIN SPEAKERS 64 W per channel min. RMS both channels driven into
6 Ω at 1 kHz with no more than 0.9% total harmonic
distortion.
Audio input sensitivity/Impedance
(Measured at 1 kHz with tape record-
ing signal 300 mV)
AUX 400 mV/50 kΩ
MIC 3 mV/10 kΩ
Tuner
FM tuning range 87.50 MHz to 108.00 MHz
AM tuning range At 9 kHz intervals 531 kHz to 1 710 kHz
At 10 kHz intervals 530 kHz to 1 710 kHz
CD player
CD capacity 3 CDs
Dynamic range 85 dB
Signal-to-noise ratio 90 dB
Wow and flutter Immeasurable
Cassette deck
Frequency response Normal (type I) 50 Hz to 14 000 Hz
Wow and flutter 0.15% (WRMS)
General
Power requirement AC 110 V / AC 127 V / AC 220 V / AC 230 V to AC 240 V (adjustable with the voltage selector)
Power consumption 50 Hz / 60 Hz
100 W (at operation)
20 W (on standby)
Dimensions (approx.) 270 mm x 306 mm x 433.5 mm (W/H/D)
Mass (approx.) 9.2 kg
Speaker Specifications
Type 3-Way 3 Speaker Bass-Reflex (Magnetically-Shielded Type)
Speakers Main woofer 15cm cone x 1
Mid Range 5.0cm cone x 1
Tweeter 2.0cm dome x 1
Power Handling Capacity 80 W
Impedance 6 Ω
Frequency Range 42 Hz to 30 000Hz
Sound Pressure Level 84 dB/W.m
Dimensions (W x H xD) 215mm x 306 mm x 243 mm
Mass 3.4 kg
