JVC SP-MXJ206 Block Diagram

MX-J200/J206
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 01
A
Item
Parts number Parts name Area
Remarks
A
C 322 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 323 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 324 GJ270112270310 E.CAPACITOR 10V M 220UF
C 325 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 326 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 327 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 328 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 329 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 330 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 331 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 364 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 381 GJ116259621 A.CAPACITOR 25V F Z 0.022UF
C 901 GJ283116832432 CAPACITOR
A
100V K 0.068UF
C 902 GJ283116832432 CAPACITOR 100V K 0.068UF
C 903 GJ283116832432 CAPACITOR
A
100V K 0.068UF
C 904 GJ283116832432 CAPACITOR
A
100V K 0.068UF
C 905 GJ270192282214 E.CAPACITOR 50V M 2200UF
C 906 GJ270192282214 E.CAPACITOR 50V M 2200UF
C 907 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 908 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 909 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 910 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 911 GJ270144780110 E.CAPACITOR 25V M 4700UF
C 912 GJ112491891 E.CAPACITOR 47MF 20% 63V
C 913 GJ270192260310 E.CAPACITOR 50V VX M 22UF
C 914 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 915 GJ270192260310 E.CAPACITOR 50V VX M 22UF
C 916 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 917 GJ270192250310 E.CAPACITOR
A
50V VX M 2.2UF
C 918 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 919 GJ270111070310 E.CAPACITOR 10V M 100UF
C 920 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 921 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 922 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 923 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 924 GJ270124760310 E.CAPACITOR 16V M 47UF
C 925 GJ270112260310 E.CAPACITOR 10V M 22UF
CF 1 GJ178140611 CERAMIC FILTER
CF 2 GJ178140611 CERAMIC FILTER
CF 3 GJ178117111 DESCRIMINATOR
CN301 GJ340022090108 CONNECTOR 9PIN BLK
CN302 GJ340072040102 CONNECTOR 4PINS
CN303 GJ340022190108 CONNECTOR 19PINS
CN304 GJ340022130108 CONNECTOR 13PIN BLK
CN305 GJ340022130108 CONNECTOR 13PIN BLK
CN91A GJ340072040102 CONNECTOR 4PINS 1/2
CN91B GJ340072050102 CONNECTOR 5PINS 2/2
D 1 1SS133T-77 DIODE GJ871999133
D 2 1SS133T-77 DIODE GJ871999133
D 3 1SS133T-77 DIODE GJ871999133
D 4 1SS133T-77 DIODE GJ871999133
D 5 SVC203SPA-JV-T DIODE GJ310050080104
D 6 SVC203SPA-JV-T DIODE GJ310050080104
D 7 1SS133T-77 DIODE GJ871999133
D 8 1SS133T-77 DIODE GJ871999133
D 9 1SS133T-77 DIODE GJ871999133
D 10 1SS133T-77 DIODE GJ871999133
D 11 1SS133T-77 DIODE GJ871999133
D 12 1SS133T-77 DIODE GJ871999133
D 301 MTZJT-775.1A ZENER DIODE GJ871992333
D 302 1SS133T-77 DIODE GJ871999133
D 303 1SS133T-77 DIODE GJ871999133
D 304 1SS133T-77 DIODE GJ871999133
D 305 1SS133T-77 DIODE GJ871999133
D 307 1SS133T-77 DIODE GJ871999133
D 308 1SS133T-77 DIODE GJ871999133
D 309 1SS133T-77 DIODE GJ871999133
D 311 1SS133T-77 DIODE GJ871999133
D 312 1N4003S-P DIODE GJ310020300203
D 314 1SS133T-77 DIODE GJ871999133
D 315 1SS133T-77 DIODE GJ871999133
D 316 1SS133T-77 DIODE GJ871999133
D 317 1SS133T-77 DIODE GJ871999133
D 318 1SS133T-77 DIODE GJ871999133
D 901 GJ310020320223 DIODE
A
D 902 1N4003S-P DIODE
A
GJ310020300203
D 903 1N4003S-P DIODE
A
GJ310020300203
D 904 1N4003S-P DIODE
A
GJ310020300203
D 905 1N4003S-P DIODE
A
GJ310020300203
D 906 1N4003S-P DIODE GJ310020300203
D 907 MTZJT-7733C ZENER DIODE GJ871998334
D 908 MTZJT-776.2A ZENER DIODE GJ871992341
D 909 1SS133T-77 DIODE GJ871999133
D 910 MTZJT-776.2A ZENER DIODE GJ871992341
D 911 MTZJT-775.6C ZENER DIODE GJ871992339
D 912 MTZJT-7713C ZENER DIODE GJ871992385
D 913 MTZJT-7712C ZENER DIODE GJ871992381
D 914 1SS133T-77 DIODE GJ871999133
D 915 MTZJT-776.8B ZENER DIODE GJ871992346
D 916 MTZJT-7710A ZENER DIODE GJ871992370
FW303 GJ353190150110 CABLE 19PIN
IC 1 TA2104BN IC GJ313020351101
IC 2 LC72136N IC GJ313070221000
IC301 TDA7442D IC GJ313070511342
IC302 BA15218 IC GJ313010023103
IC303 BA15218 IC GJ313010023103
IC304 STK402-070 IC GJ313040571406
J 301 GJ342030140109 JACK RCA 4PINS
J 302 GJ342040140109 HP JACK
J 302 GJ342060010111 HP JACK
J 303 GJ342020150913 JACK SPK 4PINS
L 1 VQC1505-002L COIL GJ320020260109
L 2 GJ320050190103 COIL
L 6 GJ320020270109 COIL
L 8 GJ141052131 MICRO INDUCTOR 100UH 5%
L 9 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 10 GJ141414631 INDUCTOR 2.2UH 5%
L 51 GJ141033631 INDUCTOR 220UH 10%
L 101 GJ320080170105 COIL
L 201 GJ320080170105 COIL
L 301 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 302 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 303 GJ241131001301 F.BEAD INDUCTOR 10UH
L 304 GJ141039721 F.BEAD INDUCTOR 1.1UH
LC 1 GJ123671122 FILTER
Q
1 2SC1923/O/-T TRANSISTOR GJ312010162201
Q
5 DTC114YSTP TRANSISTOR GJ872990437
Q
6 DTC114YSTP TRANSISTOR GJ872990437
Q
7 DTA114YSTP TRANSISTOR GJ872990281
Q
8 DTC114YSTP TRANSISTOR GJ872990437
Q
102 KTC3199TPGR TRANSISTOR GJ312030111210
Q
103 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
104 2SA1175TP-F TRANSISTOT GJ872910154
Q
105 2SD2144S/VW/-T TRANSISTOR GJ872992241
Q
202 KTC3199TPGR TRANSISTOR GJ312030111210
Q
203 2SD2144S/VW/-T TRANSISTOR GJ872992241
(Main board)
J206C
J200J/C
