1-18 (No.YD091)
4.4 Mechanism assembly/disassembly procedure table
Step/Loc
No.
Part Name Fig. No.
Point Note Discription
1 [A] Cassette housing assembly/ [B] Mechanism assembly T 4-5-1 2(S1),(L1) (L5) 1
2 [1] Drum assembly T 4-5-2 3(S2) 2,3
3 [2] Motor bracket assembly T 4-5-2 4(S2) 2,4
4 [3] Middle catcher assembly T 4-5-3 3(S2)
5 [4] Reel cover assembly T 4-5-3 (S2), 2(L6) 5
6 [5] Pinch roller arm assembly T 4-5-4 (W1), (L7) 6
7 [6] Sub brake assembly T 4-5-4 (P1), (W1), (L8)
8 [7] Band arm plate sub assembly T 4-5-4 (S3), (L9), (P2), (W2) 7,8
9 [8] Tension arm sub assembly T 4-5-4 (P3) 8
10 [9] Exit guide arm assembly T 4-5-5 (W1)
11 [10] Swing arm assembly T 4-5-5 Position alignment
12 [11] Sub deck assembly T 4-5-6 4(S2) 9 Position alignment
13 [12] Main brake (Supply) assembly T 4-5-6 (P4), (L10)
14 [13] Main brake (Take up) assembly T 4-5-6 (P5), (L11)
15 [14] Reel disk assembly (Supply) T 4-5-7
16 [15] Reel disk assembly (Take up) T 4-5-7
17 [16] Prism T 4-5-7 (S2)
18 [17] Control plate T 4-5-7 2(L12)
19 [18] Guide rail (Take up) assembly T 4-5-8 4(S2) 10 Position alignment
20 [19] Guide rail (Supply) assembly T 4-5-8 (S2), 2(L13) 10 Position alignment
21 [20] Base plate assembly T 4-5-8 (S2), 2(L14)
22 [21] Ent. guide base assembly T 4-5-9 (S2)
23 [22] Worm wheel 2 T 4-5-9 11 Phase alignment
24 [23] Timing belt T 4-5-9
25 [24] Center gear assembly T 4-5-9
26 [25] Reel drive pulley assembly T 4-5-10 (W1)
27 [26] Push plate T 4-5-10 (W1)
28 [27] Clutch lock gear (2) T 4-5-10
29 [28] Clutch lock gear (1) T 4-5-10 (P6)
30 [29] Tension control arm assembly T 4-5-11 (L15) 12 Position alignment
31 [30] Brake control arm assembly T 4-5-11 (W1), (L16) 12 Position alignment
32 [31] Charge arm assembly T 4-5-11 (L17) 13 Position alignment
33 [32] Connect gear 2 T 4-5-12 (S2) (Phase alignment)
34 [33] Connect gear 2 T 4-5-12 (S2) (Phase alignment)
35 [34] Rotary encoder assembly T 4-5-13 2(S2) 14 Phase alignment
36 [35] Main cam T 4-5-13 (W1) 15 Phase alignment
37 [36] Arm gear 1 assembly T 4-5-13 Collar 15,16 Position alignment
38 [37] Centering arm assembly T 4-5-13 (L18) 15 Position alignment
39 [38] Sub cam T 4-5-14 (S2) 17 Phase alignment
40 [39] Arm gear 2 assembly T 4-5-14 17 Position alignment
41 [40] Clutch lock lever assembly T 4-5-14 (L19) 17,18 Position alignment
42 [41] Capstan motor T 4-5-15 (P7), Adjust nut Vertical adjustment
43 [42] Drum base deck T 4-5-15 3(S2)
