1-2 (No.MB211)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier Section-CA-UXS57 Output Power (IEC 268-3) 120 W (60 W + 60 W) at 6 Ω (10% THD)
Analog input sensitivity/Impedance (at 1 kHz) AUX/DVD:400 mV/48 kΩ
Speakers/Impedance 6 Ω - 16 Ω
Tuner FM tuning range 87.50 MHz-108.00 MHz
AM (MW) tuning range 522 kHz-1 629 kHz
CD player CD Capacity 5 CDs
Dynamic range 87 dB
Signal-to-noise ratio 90 dB
Wow and flutter Immeasurable
General Power requirement AC 230 V , 50 Hz
Power consumption 110 W (at operation)
17 W (on standby)
1.4 W (in power save mode)
Dimensions (W/H/D) (approx.) 175 mm × 240 mm × 378 mm
Mass (approx.) 7.4 kg
Speaker Section-SP-UXS57 Type 2-way bass-reflex type
Speakers Woofer 12 cm cone × 1
Tweeter 4 cm cone × 1
Power handling capacity 60 W
Impedance 6 Ω
Frequency range 53 Hz to 30 kHz
Sound pressure level 84 dB/W·m
Dimensions (W/H/D) (approx.) 145 mm × 239.5 mm × 202 mm
Mass (approx.) 2.2 kg each
