Kaco blueplanet 125 TL3 Operating Instruction

KACO blue-
planet 87.0
TL3 M1 WM
OD IIF0
KACO blue-
planet 92.0
TL3 M1 WM
OD IIG0
KACO blue-
planet 110
TL3 M1 WM
OD IIK0
KACO blue-
planet 125
TL3 M1 WM
OD IIP0
KACO blue-
planet 137
TL3 M1 WM
OD IIP0
KACO blue-
planet 150
TL3 M1 WM
OD IIQ0
Initial short-circuit alternat-
ing current (Ik" first single
period effective value)
137 A
Short circuit current continu-
ous [ms] (max output fault
current)
134 A
Inrush current 5 A [RMS (20ms)]
Rated frequency 50/60 Hz
Frequency range 45 - 65 Hz
Reactive power 0-100 % Snom
cos phi 1 - 0.3 ind/cap
Number of feed-in phases 3
Distortion factor (THD) < 3 % 3 % 2.8 % < 3 %
Max. voltage range (up to
100 s)
475 V 500 V 600 V 750 V 825 V
AC overvoltage protection Base
4.2 General Data
KACO blue-
planet 87.0
TL3 M1 WM
OD IIF0
KACO blue-
planet 92.0
TL3 M1 WM
OD IIG0
KACO blue-
planet 110
TL3 M1 WM
OD IIK0
KACO blue-
planet 125
TL3 M1 WM
OD IIP0
KACO blue-
planet 137
TL3 M1 WM
OD IIP0
KACO blue-
planet 150
TL3 M1 WM
OD IIQ0
General electrical data
Max. efficiency 99.0 % 98.8 % 99.1 % 99.2 %
European efficiency 98.6 % 98.5 % 98.8 % 99.0 %
Self consumption: Standby < 10 W
Feed-in from > 200 W
Transformer unit no
Protection class / over
voltage category
I / III
Grid monitoring Country-specific
Distribution system TN-C system, TT system, Solid grounded wye
KACO blue-
planet 87.0
TL3 M1 WM
OD IIF0
KACO blue-
planet 92.0
TL3 M1 WM
OD IIG0
KACO blue-
planet 110
TL3 M1 WM
OD IIK0
KACO blue-
planet 125
TL3 M1 WM
OD IIP0
KACO blue-
planet 137
TL3 M1 WM
OD IIP0
KACO blue-
planet 150
TL3 M1 WM
OD IIQ0
General Data
Display LEDs
Controls Button / web server
Menu languages EN; DE; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces 2 x Ethernet, USB, 2x RS485 (1x reserviert für Stringcombiner Kom.), optional
Communication TCP/IP, Modbus TCP, Sunspec
Potential-free relay yes (integrated switch)
DC isolator switch no / yes (XL version)
AC isolator switch no
Cooling temp. regulated fan, max air throughput 364 m³/h
Number of fans 3x outside, 1x inside
KACO blueplanet 87.0 TL3 KACO blueplanet 92.0 TL3 KACO blueplanet 110 TL3 KACO blueplanet 125 TL3
KACO blueplanet 137 TL3 KACO blueplanaet 150 TL3
Page 12
EN

Kaco blueplanet 125 TL3 Specifications

General

Brand	Kaco
Model	blueplanet 125 TL3
Category	Inverter
Language	English
