Description
. Mode of Operation
The inverter converts the DC voltage generated by the PV modules into AC voltage and feeds it into the grid. The
feed-in process begins when there is su cient sunlight and a speci c minimum voltage is present in the inverter.
If, as it gets dark, the voltage drops below the minimum voltage value, the feed-in operation ends and the inverter
switches o .
. Description of the unit
.. Powador inverter as part of a PV system
... System layout
KWhKWh
Figure : Overview circuit diagram for a system with two inverters
Grid connection point
Main switch
Selective
main switch
Reference
counter
Feed-in meter
Load
Fuse
Fuse
Inverter with DC
disconnect
Inverter with DC
disconnect
PV generator
PV generator
