Technical specifications
HDS 6/14
Main Supply
Voltage V 230 240 220
Current type Hz 1~ 50 1~ 50 1~ 60
Connected load kW 3,6 3,6 3,6
Protection (slow) A 16 16 16
Type of protection -- IPX5 IPX5 IPX5
Protective class -- I I I
Maximum allowed net impedance Ohm 0.3710 0.3710 0.3710
Water connection
Max. feed temperature °C 30
Min. feed volume l/h (l/min) 800 (13,3)
Suck height from open container (20 °C) m 0,5
Max. feed pressure MPa (bar) 1 (10)
Performance data
Water flow rate l/h (l/min) 240-560 (4-9,3)
Operating pressure of water (using standard nozzle) MPa (bar) 3-14 (30-140)
Max. excess operating pressure (safety valve) MPa (bar) 17 (170)
Steam flow rate l/h (l/min) 240-290
(4-4,8)
240-290
(4-4,8)
240-265
(4-4,4)
Max. operating pressure for working with steam (using
steam nozzle)
MPa (bar) 3,2 (32)
Part no. of steam nozzle -- 2.114-000.0
Max. operating temperature of hot water °C 98
Working temperature steam operation °C 155
Detergent suck in l/h (l/min) 0-33,6 (0-0,56)
Burner performance kW 43
Maximum consumption of heating oil kg/h 3,5
Max. recoil force of trigger gun N 25,6
Size of standard nozzle -- 036 036 035
Values determined as per EN 60335-2-79
Noise emission
Sound pressure level L
pA
dB(A) 76
Uncertainty K
pA
dB(A) 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 94
Hand-arm vibration value
Hand spray gun m/s
2
2,7
Spray lance m/s
2
5,4
Uncertainty K m/s
2
0,3
Fuel
Fuel -- Fuel oil EL or Diesel
Amount of oil l 0,3
Oil grade -- 0W40
Dimensions and weights
Length x width x height mm 1060 x 650 x 920
Typical operating weight kg 108,1
Fuel tank l 15,5
Detergent Tank l 15,5
35EN
