Kärcher CV 38/2 User Manual

QUICKSTART
5.964-157.0 01/15
4
A B C Brush roller operation
ATTENTION
Risk of damage to the floor covering.
Do not operate the appliance on the spot.
A Set the pile height via the adjustment knob
of the brush head.
B Push the unlocking mechanism of the brush
head and tilt the handle backwards.
Brush motor switches on.
Perform the cleaning operation.
C The electronic brush control continuously
monitors the work of the brush roller.
No light
Brush roller is working properly.
Orange light is glowing
Set the adjustment knob for pile height to the
lower pile height.
Orange light also glows at lowest level
Replace the brush roller.
5
A B C Suction pipe operation
ATTENTION
When you vacuum with the suction hose, the
device must lock into place in the home position
in order to allow the brush motor to switch off
A Bring the handle in a vertical position and
snap it into place on the brush head.
B Pull the suction pipe out toward the top.
C Perform the cleaning operation.
Finish operation
6
A B Turn off the appliance.
A Switch off the appliance at the main switch.
B Pull out the mains plug.
Wind the mains cable around the cable
holders.
Operation

Kärcher CV 38/2 Specifications

General

Motor power	- W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Maximum input power	850 W
Annual energy consumption	37.4 kWh
Airflow	40 l/s
Product type	Upright vacuum
Dust capacity	5.5 L
Product color	Black, Grey
Tube material	-
Dust container type	Dust bag
Standard nominal width	- mm
Noise level	80 dB
Cleaning surfaces	Carpet
Vacuum air filtering	HEPA
Dirt separating method	Filtering
Working width (standard brush)	380 mm
Cord length	12 m

Weight and Dimensions

Depth	391 mm
Width	351 mm
Height	1215 mm
Weight	9500 g
Weight (without accessories)	8700 g
