ALJ/ALS/PLJ/PLS-BA-e-1640
KERN ALS 160-4A ALS 250-4A
Weighing range (max) 160 g 250 g
Readability (d) 0.1 mg 0.1 mg
Reproducibility 0.1 mg 0.1 mg
Linearity ± 0.3 mg ± 0.3 mg
Stabilization time (typical) 4 sec. 4 sec.
Minimum unit weight at
piece counting
> 0.5 mg > 0.5 mg
Warm-up time 8 hours
Recommended adjustment weight,
not added (class)
150 g (E2) 200 g (E2)
Reference quantities at
piece counting
10, 25, 50, 100 freely selectable
Weighing Units
ct, g, gn, lb, mo, oz, ozt,
tl (HK), tl (Singap. Malays), tl (Tw), pen
Electric Supply 24 V AC, 500 mA
Operating temperature + 5° C …. + 35° C
Humidity of air max. 80 % (not condensing)
Housing (B x D x H) mm 210 x 340 x 330
Dimensions of windshield
(B x D x H) mm
160 x 140 x 205 (inside)
190 x 195 x 225 (outside)
Weighing plate (stainless steel) Ø 80 mm
Weight kg (net) 5.7 kg
Interface RS 232C
