6. Troubleshooting
6.1. BMS Protection / Alarm Conditions
Alarm events cause the ALARM LED on the front panel to flash. Protection events cause the
ALARM LED to flash and will cause the HAB to shut down for the indicated time period.
Alarm / Protection Condition
Trigger Values
High Voltage Alarm for each Cell
3.55±0.03 V
High Voltage protection for each cell
3.75±0.03 V, Delay time:1s
High Voltage release for each cell
3.40±0.03 V
High Voltage alarm for total voltage
56.8 V±0.5 V
High Voltage protection for total voltage
60.0 V±0.5 V, Delay time:1s
High Voltage release for total voltage
54.4 V±0.5 V
High Voltage release method
Under the release voltage (54.4 V±0.5 V) for 1s
Low Voltage alarm for each cell
3.00±0.03 V
Low Voltage protection for each cell
2.70±0.03 V, Delay time:1s
Low Voltage release for each cell
3.10±0.03 V
Low Voltage alarm for total voltage
48.0 V±0.5 V
Low Voltage protection for total voltage
43.2 V±0.5 V, Delay time:1s
Low Voltage release for total voltage
49.6 V±0.5 V
Low Voltage release method
Charge to recovery
Charge over current alarm
165±5 A
Charge over current protection
180±5 A, Delay time:5s
Charge over current release method
Auto release after 1min
Discharge over current alarm
165±5 A
Discharge over current protection
180±10 A, Delay time:1s
Over current release method
Auto release after 1min
Charge High Temperature alarm
122°F ± 5.4°F (50°C ± 3°C)
Charge High Temperature protection
131°F ±5.4°F (55°C ± 3°C)
Charge High Temperature release
113°F ±5.4°F (45°C ± 3°C)
Discharge High Temperature alarm
140°F ±5.4°F (60°C ± 3°C)
Discharge High Temperature protection
149°F ±5.4°F (65°C ± 3°C)
Discharge High Temperature release
131°F ±5.4°F (55°C ± 3°C)
Charge Low Temperature Alarm
37.4°F ±5.4°F (3°C ± 3°C)
