How To Install The Faucet
Screw the stud(1) to the thread hole on the bottom of faucet. Put the
washer(2) into the bottom of body(4) through the flexible hoses(3) and
the stud. Insert hoses(3) and stud into the hole of lavatory. Position
the faucet. From underside of the lavatory, fit the bracket(5) and
washer(6) on the stud. Secure the faucet by tightening nut(7).
Attach the hoses to water supplies.
Note: The hose with red mark is connected to hot water.
6
1
5
3
2
4
7
How To Install The Drain(Not For 16231-4ND)
Remove the locknut(13), plastic washer(12), rubber gasket(11) and
tailpiece(10) from the drain body. Supply enough tape or sealant to
tailpiece thread. Reinstall the tailpiece. Insert the drain body into the
lavatory. Put the rubber gasket (tapered side up), plastic washer and
locknut back to the drain body in turn. Tighten the locknut.
NOTE: If needed, apply a ring of plumbers putty or other sealants
around the underside of the drain flange(8), instead of using rubber
washer(9).
Do not reposition the drain after the locknut is tightened, or you may
break the putty or sealant seal.
INSTALLATION CHECKOUT
Ensure all coupling nuts are tightened.
Ensure that handle is in the off position.
Turn on the darin and main water supply. Check for leaks. Repair as
required.
Remove aerator assembly(14). Turn faucet handle on. Run hot and
cold water through spout for about one minute to remove any debris.
Check for leaks at this time. Remove any debris from aerator
assembly. Shut the faucet off and reinstall aerator assembly.
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
16230-4 SINGLE HOLE LAV FAUCET
16231-4/4ND SINGLE HOLE TALL LAV FAUCET
Single Lever / Single Control
1046290
Hex Wrench
1054202
Bearing
1041023
Screw
1054197**
Ball connector
1010167
O-Ring
1054201
Spring
1070773**
(Only for 16230-4)
Handle
1070774**
(Only for 16231-4)
1195036**
Aerator Assy
1191840**
(Only for Thailand)
880096
Hose
1081483
Mounting Hardware
1054199**
Sliding Disk
1019863**
Nut
1054200
Valve
1054198**
Cap
1095926**
Click Drain
(Not for 16231-4ND)
1102892
Piston Kit
1102889
Washer
1102888**
Stopper
10
11
12
13
14
Drain body
9
8
