OPERATION
EXPLANATION OF COMPONENTS
AIR CONDITIONER
(If equipped)
By taking fresh air into the cab through a filter, it is possible to raise the pressure inside the cab. This makes it
possible to provide a pleasant working environment even on dusty jobsites.
GENERAL LOCATIONS ON CONTROL PANEL
(1)
(2)
(3)
Fan switch
Air conditioner switch
Mode selector switch
(4)
(5)
External/Internal air changeover switch
Temperature control switch
FAN SWITCH
This switch (1) can be used to adjust the air flow to 4 stages.
This switch also acts as the main switch for the air conditioner.
When the switch is pressed, the indicator lamp above the switch
lights up to indicate the air flow.
3 - 64
