KTM 1290 Super Duke R 2017 User Manual

30 LIST OF SYMBOLS 237
30.1 Red symbols
Red symbols indicate an error condition that requires immediate intervention.
The oil pressure warning lamp lights up red – Engine oil pressure is too low.
30.2 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are also represented by yellow
or orange symbols.
Malfunction indicator lamp lights up/flashes yellow – The engine electronics has detected a fault.
ABS indicator lamp lights up/flashes yellow – The ABS is not activated on one or both wheels. The ABS indicator
lamp also lights up if an error is detected.
TC indicator lamp lights up/flashes yellow – Traction control is not enabled or is currently intervening. The TC Indi-
cator lamp also lights up if an error is detected. The TC indicator lamp flashes if the launch control (optional) is
activated.
Race-on indicator lamp lights up/flashes yellow/orange/red – Status or error messages relating to Race-on
system/alarm system.
The general warning lamp lights up yellow – An operating safety (warning) message was detected. This is also
shown on the combination instrument.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
