KTM 1290 Super Duke R 2017 User Manual

7 COMBINATION INSTRUMENT 45
7.1 Combination instrument
E00727-10
The combination instrument is attached in front of the handlebar.
The combination instrument is divided into two function areas.
Display
1
2
Indicator lamps ( p. 48)
7.2 Activation and test
S01734-10
Activation
The combination instrument is activated when the ignition is switched on.
Info
The brightness of the displays is controlled by a brightness sensor in the combina-
tion instrument.
Test
The welcome text appears on the display and the indicator lamps are briefly activated for a
function test.

KTM 1290 Super Duke R 2017 Specifications

General

Displacement	1301 cc
Bore x Stroke	108 mm x 71 mm
Fuel System	Keihin EFI, 56 mm throttle bodies
Transmission	6-speed
Rear Suspension	WP monoshock
ABS	Bosch 9ME Combined ABS
Front Tire	120/70 ZR 17
Rear Tire	190/55 ZR 17
Seat Height	835 mm
Dry Weight	195 kg
Power	177 hp
Torque	141 Nm
Frame	Chromium-Molybdenum steel trellis frame
Front Suspension	WP Ø 48 mm
Front Brake	Dual 320 mm discs, Brembo 4-piston calipers
Rear Brake	Brembo two-piston caliper, 240 mm disc
Wheelbase	1482 mm
Fuel Tank Capacity	18 liters
