KTM 1290 SUPER DUKE R 2021 User Manual

COMBINATION INSTRUMENT 7
61
7.44 MUSIC widget
S03840-10
– Press the UP button once when the menu is closed.
– Use the LEFT or RIGHT button to change between the informa-
tion displays until the MUSIC widget is displayed.
Warning
Danger of accidents Headphone volume which is too
high distracts attention from traffic activity.
– Always select headphone volume which is low
enough for you to still clearly hear acoustic signals.
– Press the SET button to open the large widget.
– Press the UP button to increase the volume.
– Press the DOWN button to reduce the volume.
– Press the RIGHT button briefly to change to the next audio
track.
– Depending on the cellphone model, press the LEFT button
briefly or twice to change to the previous audio track or to play
the current audio track from the start.
– Press the SET button to change between playback and pause.
Tip
The MUSIC widget is only available if a cellphone and a
headset are connected via Bluetooth
®
with the motorcy-
cle.
With some cellphones, the cellphone's audio player
needs to be started before playback is possible. For
easier operation, the MUSIC function can be added to
the C1 or C2 switch.

KTM 1290 SUPER DUKE R 2021 Specifications

General

Displacement	1301 cc
Transmission	6-speed
Rear Suspension	WP APEX monoshock, fully adjustable
Seat Height	835 mm
Fuel Tank Capacity	16 liters
Dry Weight	189 kg
Bore x Stroke	108 mm x 71 mm
Compression Ratio	13.5:1
Fuel System	Electronic fuel injection
Lubrication	Forced oil lubrication with 3 oil pumps
Wheelbase	1482 mm
Traction Control	MTC (Motorcycle Traction Control), lean-angle sensitive
Engine Type	V-Twin, 4-stroke
Power	180 hp
Torque	140 Nm @ 8000 rpm
Frame	Chromium-Molybdenum steel frame, powder coated
Front Suspension	WP APEX 48
Front Brake	320 mm discs
Rear Brake	Brembo two-piston caliper, 240 mm disc
Clutch	PASC slipper clutch, hydraulically actuated
ABS	Bosch 9.1 MP (incl. Cornering ABS and Supermoto mode)
