Step 2: Check Valve Clearance
Slide your feeler gauge into the gap between the
valve shim and the rocker arm. The proper valve
clearance for a 2012 KTM 250 SX-F is 18-23
thousands of an inch. If you cannot fit the 18 into
the gap, then you need to put the next size smaller
shim in. If you cannot fit the 23 into the gap, then
you need to increase the valve shim size. Below is a
picture to assist you in the process.
Picture 1.6 (SM Junkie)
Rocker Arm
Valve
Shim

KTM 2012 250 SX-F Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	249.91 cc
Starter	Electric starter
Transmission	5-speed
Cooling	Liquid cooled
Rear Suspension	WP Monoshock
Fuel Tank Capacity	7.5 liters
Compression Ratio	12.8:1
Bore x Stroke	76 mm x 54.8 mm
Fuel System	Keihin EFI
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP USD 48 mm
Front Brake	260 mm disc
Rear Brake	220 mm disc
Seat Height	992 mm
Ground Clearance	375 mm
