B00074-10
– Slide the glass fiber yarn filling over the inner tube.
– Slide the outer tube over the glass fiber yarn filling.
Info
Ensure that the O-rings are seated properly.
– Insert locking cap into the outer tube.
– Mount and tighten nut .
– Install the main silencer. ( p. 80)
11.92Changing the glass fiber yarn filling of the main silencer x
B00063-00
–
Remove the glass fiber yarn filling of the main silencer. x ( p. 80)
–
Install the glass fiber yarn filling of the main silencer. x ( p. 81)
11.93Removing the air filter box lid
B00038-10
– Pull off the air filter box lid in area sideways and remove it toward the front.
11.94Installing the air filter box lid
B00038-11
– Insert the air filter box lid into the rear area and clip it into the front area .
11.95Removing the air filter x
Note
Engine failure Unfiltered intake air has a negative effect on the service life of the engine.
– Never ride the vehicle without an air filter since dust and dirt can get into the engine and result in increased wear.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
– Remove the air filter box lid. ( p. 81)
