ENGLISH
12
Hot start device
If you pull the hot start device 1 out as far as possible, a bore in the
carburetor will be opened through which the engine may take in additional
air. The result is a „lean“ fuel-air mixture of the type needed for hot starts.
To deactivate the hot start device, push the hot start button back into its
basic position.
Shift lever
The shift lever is mounted on the left side of the engine. The position of the
gears is shown in the illustration. Neutral position is located between first
and second gear.
Kickstarter
The kickstarter is mounted on the left side of the engine. Its upper part can
be swivelled.
Foot brake pedal
The foot brake pedal is located in front of the right foot rest. Its basic
position can be adjusted to your seat position (see maintenance work).
Handlebar lock
The handlebar can be locked by means of the lock located on the control
head. Fully turn handlebar to right to lock, insert key, turn to left, press in,
turn to right and withdraw.
!
CAUTION
!
N
EVER LEAVE THE KEY INSERTED IN THE LOCK. IF YOU TURN THE STEERING TO THE LEFT
THE KEY COULD GET DAMAGED
.
2,3,4,5
1
N
1
