MEANS OF REPRESENTATION 5
Symbols used
The symbols used are explained in the following.
Indicates an expected reaction (e.g. of a work step or a function).
Indicates an unexpected reaction (e.g. of a work step or a function).
Identifies a page reference (more information is provided on the specified page).
Indicates information with more details or tips.
Indicates the result of a testing step.
Identifies a voltage measurement.
Identifies a current measurement.
Identifies a resistance measurement.
Formats used
The typographical and other formats used are explained in the following.
Name Indicates a proprietary name.
Protected name
®
Identifies a protected name.
Trademarkâ„¢ Identifies a brand in merchandise traffic.
