MAINTENANCE WORK ON CHASSIS AND ENGINE 112

9.55Refitting the headlight mask with the headlight

100294-11

– Connect the connectors of headlight  and flasher lights .

– Check lighting function.

100295-10

– Remove the cloth from the fender, attach the headlight mask to points  on the fender

and swing it up to the steering head.
