MAINTENANCE WORK ON CHASSIS AND ENGINE 117
9.60Adjusting the headlight range
– Check the headlamp setting. ( p. 116)
800084-10
– Turn adjusting screw to adjust the headlight range.
Guideline
For a motorcycle with rider, the light/dark boundary must be exactly on the lower
mark (made in: Checking headlight adjustment).
Info
Turn clockwise to increase headlight range, turn counterclockwise to reduce
headlight range.
If you have a heavy payload, you will have to correct the headlight range.
9.61Removing the air filter x
– Remove the seat. ( p. 100)
100285-10
– Remove screws . Remove filter box top .
