TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 197

Screw, spring holder on side stand

bracket

M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, steering stem M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –

Upper fuel tank screw M8 20 Nm (14.8 lbf ft) –

Engine carrying screw M10 45 Nm (33.2 lbf ft)

Loctite

243™

Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft)

Loctite

243™

Screw, engine bearer on frame M10 45 Nm (33.2 lbf ft) –

Screw, foot brake lever M10LH 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar support M10 40 Nm (29.5 lbf ft) –

Screw, side stand M10 35 Nm (25.8 lbf ft)

Loctite

243™

Screw, top shock absorber M10 45 Nm (33.2 lbf ft)

Loctite

243™

Lambda sensor M12x1.25 24.5 Nm (18.07 lbf ft) Copper paste

Screw, swingarm pivot M12x1.75 80 Nm (59 lbf ft) –

Nut, linkage lever on swingarm M14x1.5 100 Nm (73.8 lbf ft) –

Nut, linkage lever to rocker arm M14x1.5 100 Nm (73.8 lbf ft) –

Screw, bottom steering head M20x1.5 60 Nm (44.3 lbf ft)

Loctite

243™

Screw, top steering head M20x1.5 10 Nm (7.4 lbf ft) –

Screw, front wheel spindle M24x1.5 40 Nm (29.5 lbf ft) –

Nut, rear wheel spindle M25x1.5 90 Nm (66.4 lbf ft) –
