SERVICE WORK ON THE ENGINE 142
100200-10
– Place a suitable container under the engine.
– Remove the oil drain plug with the magnet and seal ring.
– Completely drain the engine oil.
100201-01
– Thoroughly clean the oil drain plug with a magnet.
– Mount the oil drain plug with the magnet and seal ring and tighten it.
Guideline
Oil drain plug with magnet M12x1.5 20 Nm
(14.8 lbf ft)
16.4Removing the oil filter x
Warning
Danger of scalding Engine oil and gear oil get very hot when the motorcycle is ridden.
– Wear appropriate protective clothing and safety gloves. In case of burns, rinse immediately with lukewarm water.
