TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 12

4TECHNICAL DATA- CHASSIS TIGHTENINGTO RQUES

Remaining screws, chassis M5 4Nm (3lbfft) –

Spoke nipple, front wheel M4,5 4Nm (3lbfft) –

Spoke nipple, rear wheel M5 4Nm (3lbfft) –

Screw, exhaust heat shield M5 8Nm (5.9lbfft) –

Screw, electrical holder M5 3Nm (2.2lbfft) –

Screw, footbrake pedal foothold M5 6Nm (4.4lbfft)

Loctite

243™

Screw, fuel pump M5 6Nm (4.4lbfft) –

Screw, fuel level indicator M5 3Nm (2.2lbfft) –

Screw, side cover M5 2Nm (1.5lbfft) –

Screw, headlight mask M5 5Nm (3.7lbfft) –

Screw, side stand switch M5 3Nm (2.2lbfft) –

Screw, seat lock M5 3Nm (2.2lbfft)

Loctite

222

Screw, starter cable on starter M5 3Nm (2.2lbfft) –

Nut, foot brake cylinder screw M6 10Nm (7.4lbfft) –

Remaining nuts, chassis M6 15Nm (11.1lbfft) –

Remaining screws on fuel tank M6 6Nm (4.4lbfft) –

Remaining screws, chassis M6 10Nm (7.4lbfft) –

Screw, brake fluid reservoir of rear

brake

M6 5Nm (3.7lbfft) –

Screw, rear brake disc M6 14Nm (10.3lbfft)

Loctite

243™

Screw, front brake disc M6 14Nm (10.3lbfft)

Loctite

243™

Screw, license plate holder, bottom M6 8Nm (5.9lbfft) –

Screw, ball joint of push rod on foot-

brake cylinder

M6 10Nm (7.4lbfft)

Loctite

243™

Screw, radiator bracket M6 5Nm (3.7lbfft) –

Screw, magnetic holder on side stand M6 10Nm (7.4lbfft)

Loctite

243™

Screw, voltage regulator/rectifier M6 8Nm (5.9lbfft) –

Screw, SLS valve M6 4Nm (3lbfft) –

Screw, ignition lock M6 10Nm (7.4lbfft)

Loctite

243™

Nut, rear sprocket screw M8 35Nm (25.8lbfft)

Loctite

243™

Nut, manifold on cylinder head M8 25Nm (18.4lbfft) Copper paste

Remaining nuts, chassis M8 30Nm (22.1lbfft) –

Remaining screws, chassis M8 25Nm (18.4lbfft) –

Screw, exhaust clamp on main silencer M8 25Nm (18.4lbfft) –

Screw, front brake caliper M10x1.25 45Nm (33.2lbfft)

Loctite

243™

Screw, main silencer holder M8 25Nm (18.4lbfft) –

Screw, main silencer holder on fuel

tank

M8 25Nm (18.4lbfft)

Loctite

243™

Screw, heel protector M8x12 8Nm (5.9lbfft) –

Screw, rear footrest bracket M8x16 25Nm (18.4lbfft) –

Screw, front footrest bracket M8 25Nm (18.4lbfft) –

Screw, spring holder on side stand

bracket

M8 25Nm (18.4lbfft)

Loctite

243™

Screw, top triple clamp M8 17Nm (12.5lbfft) –

Screw, bottom triple clamp M8 12Nm (8.9lbfft) –

Screw, fork stub M8 15Nm (11.1lbfft) –

Screw, steering stem M8 20Nm (14.8lbfft)

Loctite

243™

Screw, handrail M8 20Nm (14.8lbfft) –

Screw, license plate holder, top M8 20Nm (14.8lbfft) –

Screw, fuel tank, top M8 25Nm (18.4lbfft)

Loctite

243™

Screw, fuel tank, bottom M8 25Nm (18.4lbfft) –

Screw, handlebar clamp M8 20Nm (14.8lbfft)

Loctite

243™

Screw, side stand bracket M8 25Nm (18.4lbfft) –

Questions and Answers:

Need help?

Do you have a question about the KTM 690 SMC 2008 and is the answer not in the manual?

KTM 690 SMC 2008 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	654 cc
Bore x Stroke	102 mm x 80 mm
Compression Ratio	11.8:1
Cooling System	Liquid cooled
Transmission	6-speed
Front Brakes	Single 320 mm disc, 4-piston caliper
Rear Brakes	Single 240 mm disc, 1-piston caliper
Front Tire	120/70 ZR17
Rear Tire	160/60 ZR17
Dry Weight	139 kg
Fuel Capacity	12 liters
Seat Height	890 mm
Starter	Electric
Lubrication	Pressure lubrication with 2 Eaton pumps
ABS	Not available
Front Wheel	3.50 x 17"
Rear Wheel	5.00 x 17"
Power	46 kW (63 hp) at 7500 rpm
Fuel System	Keihin EFI
Front Suspension	WP USD Ø 48 mm
Rear Suspension	WP shock absorber
Clutch	hydraulically operated
Frame	Chromium-Molybdenum trellis frame, powder-coated
Torque	65 Nm @ 6, 500 rpm
