KTM 690 SMC User Manual

TROUBLESHOOTING 148
10TROUBLESHOOTING
Faults Possible cause Action
Engine does not turn when the electric
starter button is pressed
Operating error – Carry out the instructions for starting.
( S. 49)
Battery discharged –
Recharge the battery.x ( S. 112)
– Check the cause of discharging.
Fuse1,2,3,or4 blown – Change the fuses of individual power
consumers. ( S. 116)
Main fuse burned out – Change the main fuse. ( S. 114)
Ignition/steering lock or emergency OFF
switch defective
– Have ignition/steering lock or emergency
OFF switch checked.
Defect in safety start system – Have the safety start system checked.
Engine turns only if the clutch lever is
drawn
The vehicle is in gear – Shift gear to neutral.
The vehicle is in gear and the side stand is
folded out
– Shift gear to neutral.
Defect in safety start system – Have the safety start system checked.
Engine turns although a gear is engaged Defect in safety start system – Have the safety start system checked.
Engine turns but does not start. Operating error – Carry out the instructions for starting.
( S. 49)
Fuse4 blown – Change the fuses of individual power
consumers. ( S. 116)
Coupling of fuel hose connection not con-
nected
– Reconnect coupling of fuel hose connec-
tion.
Socket connector of cable harness oxidized – Clean socket connector and treat it with
contact spray.
Defect in fuel injection system – Read the error memory with the KTM
diagnostics tool and correct the fault.
Engine has too little power. Air filter very dirty – Have the air filter changed.

KTM 690 SMC Specifications

General

Bore x Stroke	105 mm x 80 mm
Starter	Electric starter
Transmission	6-speed
Lubrication	Forced oil lubrication with 2 oil pumps
Clutch	APTC slipper clutch, hydraulically actuated
Frame	Chromium-Molybdenum steel trellis frame, powder coated
Tires Front	120/70 ZR 17
Tires Rear	160/60 ZR 17
Steering Head Angle	63.5°
Seat Height	890 mm
Engine Type	1-cylinder, 4-stroke engine
Fuel System	Electronic fuel injection
Cooling	Liquid cooled
Front Brake	Brembo four piston radial caliper, 320 mm disc
Rear Brake	Brembo single piston caliper, 240 mm disc
Wheels Front	3.50 x 17"
Wheels Rear	5.00 x 17"
Fuel Capacity	13.5 l
Power	55 kW (74 hp)
Wheelbase	1, 480 mm ± 15 mm
