COMBINATION INSTRUMENT 7
29
7.6 Indicator lamps
F01768-01
The indicator lamps offer additional information about the operating state of the motorcycle.
When the ignition is switched on, all indicator lamps light up briefly, except for the TC indicator lamp .
Info
The malfunction indicator lamp always lights up as long as the engine is not running. If the engine
is running and the malfunction indicator lamp lights up, stop (taking care not to endanger yourself or
other road users in the process) and contact an authorized KTM workshop.
The oil pressure warning lamp always lights up as long as the engine is not running. If the engine is run-
ning and the oil pressure warning lamp lights up, stop immediately (taking care not to endanger yourself
or other road users in the process) and switch off the engine.
The ABS warning lamp and TC indicator lamp light up until a speed of approx. 6 km/h (approx.
4 mph) or more has been reached.
Possible states
The turn signal indicator lamp flashes green simultaneously with the turn signal – The turn
signal is switched on.
Malfunction indicator light lights up yellow – The OBD has detected a malfunction in the vehi-
cle electronics. Come safely to a halt, and contact an authorized KTM workshop.
ABS warning lamp lights up/flashes yellow – Status or error messages relating to ABS. The
ABS warning lamp flashes if the ABS mode Offroad is enabled.
The idle indicator lamp lights up green – The transmission is in neutral.
TC indicator lamp lights up/flashes yellow – MTC ( p. 133) is not enabled or is currently
intervening. The TC indicator lamp also lights up if a malfunction is detected. Contact an
authorized KTM workshop. The TC indicator lamp flashes if MTC makes an active intervention.
