16 ELECTRICAL SYSTEM
224
16.6 Changing the ABS fuses
Warning
Fire hazard Incorrect fuses overload the electrical system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
Info
Two fuses for the ABS are located under the passenger seat. These fuses protect the return pump and the
hydraulic unit of the ABS. The third fuse, which protects the ABS control unit, is located in the fuse box.
Preparatory work
– Remove the passenger seat. ( p. 164)
V01209-10
To change the fuse of the ABS hydraulic unit:
–
Remove the protection cap and fuse
1
.
Info
A faulty fuse has a burned-out fuse wire
A
.
– Insert the spare fuse with the correct rating.
Fuse (75011088015) ( p. 286)
