Main fuse
The main fuse protects all of the motorcycle's electric power consumers. The main fuse is
located on the left under the front spoiler.
Pull the connector [1] out of the bracket, remove the cap [2] and check the main fuse [3].
A spare fuse [4] (30 amperes)is also plugged into the bracket.
Always replace blown fuses with an equivalent fuse. Visit an authorized KTM workshop if a
new fuse blows again after it is inserted.
Never use a stronger fuse or a repaired fuse. Improper use can destroy the entire electric
system.
MAINTENANCE WORK ON CHASSIS AND ENGINE »
55
1
2
4
3
